Side-by-Side Covers: How to Measure and Fit a Cover to Any UTV

Start With the Highest Point, Not the Body

The first measurement that matters is overall height, and you need to measure from the ground to whatever sits tallest on your machine — not the roofline of the cab.

If you have a whip antenna, a light bar, or a snorkel intake, that's your starting point. Stand back and look at the profile of your UTV from the side. What's the highest point? Measure from the ground straight up to that point. Don't assume the manufacturer's spec height is accurate for your setup. The spec sheet reflects the machine as it rolled off the assembly line, and that's rarely how it sits in your driveway.

For machines with soft tops or bikini tops, measure with the top in its normal operating position — not folded down. If you run the top up most of the time, that's the dimension you need. Some people try to split the difference and measure halfway, which guarantees the cover won't fit either configuration properly.

Length Includes Everything That Sticks Out the Back

Measure from the furthest forward point to the furthest rear point, and this is where people consistently underestimate.

Rear cargo boxes, spare tire carriers, and trailer hitches all add length. If you have a cooler rack or a gun boot mounted behind the cab, include it. The measurement should capture the entire length of anything that's staying on the machine during storage. Covers that fit the cab perfectly can leave several inches of cargo box exposed if the buyer forgets to account for rear-mounted accessories.

Tow hitches are easy to overlook because they sit low, but a two-inch receiver sticking out the back will catch on a cover's hem and create a gap that lets water pool on the seat. If the hitch is removable and you plan to take it off for storage, fine — measure without it.

Width Is Measured at the Widest Point, Including Mirrors

This is the measurement that causes the most returns.

Measure from the outermost point on one side to the outermost point on the other. For most UTVs, that's the mirrors. If your mirrors fold in, measure them folded — but only if you'll actually fold them every time you cover the machine. If you're like most people and leave them extended, measure them extended.

Some side-by-sides have flared fenders or wide stance suspensions that make them wider at the wheel wells than at the cab. Measure at multiple points along the length and use the widest number. Door handles, grab bars, and side-mounted tool holders all count if they protrude beyond the body line.

Club Car specifies that utility vehicle covers should allow for roughly 2-4 inches of clearance beyond the vehicle's dimensions to ensure proper fit and ventilation. That buffer matters more on width than on any other dimension because covers need to drape naturally over the sides without pulling tight across the top.

Windshields and Roof Configurations Change Everything

A UTV with a full windshield and hard roof needs a completely different cover than the same model with a half windshield and no roof.

If you run a vented windshield, measure to the top edge of the vent — not the bottom of the glass. Folding windshields should be measured in the position you store them. Some people flip the windshield down onto the hood for winter storage, which can significantly reduce the overall height while increasing the front-to-back dimension. Measure the configuration you'll actually use.

Hard tops, soft tops, and bikini tops all create different profiles. A hard top with a roof rack adds height and changes how the cover needs to drape over the cab. A soft top might compress slightly under a cover, but you still need to measure it at full extension. Bikini tops often have bows or frames that sit higher than you'd expect.

The worst-case scenario is ordering a cover based on a bare-roof measurement and then installing a top later. The cover won't fit, and you'll either need to return it or leave the top off every time you cover the machine.

Crew Cab Models Need Bed Length Measured Separately

Four-seat and six-seat crew cab models have longer wheelbases and extended cargo beds that change the proportions.

Measure the bed length independently from the cab length, because some covers are designed with a split configuration that accounts for the gap between the rear seat and the bed. If your crew cab has a dump bed, measure it in the down position unless you plan to store it tilted (which almost nobody does).

The bed rails matter too. Aftermarket bed extenders, rail caps, and tie-down systems can add several inches of height at the rear. If you have a bed cover or tonneau system installed, measure over it. Some people assume they'll remove the bed cover before using the main cover, but that's an extra step most people skip after the first time.

Account for Accessories That Stay On Year-Round

Anything permanently or semi-permanently mounted needs to be part of your measurement.

Roof racks, light bars, winches, and front bumpers all change the dimensions. If you have a full skid plate system or rock sliders, check whether they extend beyond the frame rails. Some aggressive front bumpers add several inches of length, and if the cover doesn't account for that, the cover may pull tight and either tear or leave the rear exposed.

GPS units, CB antennas, and rearview cameras are small but often sit at the highest point of the vehicle. A tall antenna might seem minor, but if the cover doesn't have clearance for it, you'll end up with a stretched spot that collects water and eventually tears.

Measure Twice With a Helper

One person holding the tape measure at the front while another reads it at the back eliminates most errors.

Use a long tape measure — at least 25 feet — and pull it taut. Flexible fabric measuring tapes don't work well for this because they sag in the middle and give you a short reading. A metal tape or a laser measure works better.

Write down each measurement as you take it. Don't rely on memory. I've watched people measure three times, get three slightly different numbers, and then guess at which one was right. Take the largest number from each dimension. If you measured the length at different values on successive attempts, use the larger number. The extra two inches of cover fabric won't hurt anything, but two inches short will.

When to Size Up vs. Sizing for Exact Fit

Most manufacturers build covers in Small, Medium, Large, X-Large ranges with dimension windows for each size.

If your measurements fall near the top of one size range, go up to the next size. A cover that's slightly large will still protect the machine and allow for airflow underneath.

The exception is if you're storing indoors in a tight space where excess fabric will drag on the floor or catch on nearby equipment. In that case, aim for the closer fit — but only if your measurements are comfortably within the size range, not at the edge.

Custom Covers for Non-Standard Builds

If you've built a heavily modified UTV with a custom cage, oversized tires, or a lifted suspension, standard covers might not work.

Lifted machines sit taller, and oversized tires increase both width and height. A lift kit and oversized tires can add significant height compared to stock configuration. Measure carefully and look for covers marketed as "lifted" or "oversized" — or consider a custom cover if your build is far enough outside standard dimensions.

Custom covers typically require you to submit measurements for multiple points on the vehicle: overall length, cab length, bed length, height at the windshield, height at the roof, height at the bed, width at the mirrors, width at the fenders, and sometimes wheelbase. The lead time typically runs longer — often several weeks — but the fit is exact.

Test the Fit Before Storing Long-Term

When the cover arrives, test-fit it in good weather before you need.

Pull it over the machine and check for gaps, tight spots, or areas where it doesn't drape naturally. Walk around the entire UTV and look for places where the fabric pulls or bunches. If the cover is too tight across the windshield or catches on the mirrors, you'll know immediately.

Most manufacturers allow returns within 30 days if the cover doesn't fit, but that window closes fast.

Check the tie-down straps and elastic hems while you're at it. The cover should sit low enough that the hem reaches below the body line on all sides, and the straps should cinch snugly without pulling the cover upward. If the elastic hem barely reaches the bottom of the door, the cover is too small.

The Detail Nobody Mentions: Covers Shrink Slightly After UV Exposure

This is the part that surprises people after the first season.

Outdoor covers made from polyester or solution-dyed fabrics may tighten slightly after months of sun exposure. The change is typically modest, but it's enough that a cover that fit perfectly when new might feel snug after a season of use. That's another reason to size up if you're between sizes. A cover that feels slightly loose initially may fit better after some time in the sun.

Virginia Cooperative Extension recommends proper storage of off-highway vehicles in covered structures to protect from weather damage and extend equipment life, but when a garage or pole barn isn't an option, a correctly fitted cover is the next best protection. The difference between a cover that works and one that doesn't comes down to careful measurement before you order.
